High Speed Food Centrifuge , Milk Separator With Large Capacity For Beverage Juice Clarification

Place of Origin : China

Brand Name : Peony

Certification : ISO9001&ISO14001,CE

Model Number : PDSM20000-CN

MOQ : 1

Packaging Details : Standard export packing

Delivery Time : 45days

Payment Terms : TT, LC

Supply Ability : 100sets per month

Machine type : 2 Phase Milk Separator

Automatic degree : Fully automatic

Phase : 2 phase

Type : Algae dewatering

Separation : Solid-liquid separation

Product type : Separation equipment

Sanitary degree : GMP

Bearing : SKF

Bowl material : SS

Operation : Easy and convenient

Contact Now

High Speed Food Centrifuge , Milk Separator With Large Capacity For Beverage Juice Clarification

Brief introduction

Model PDSM20000-CN separator is the newest generation milk separator, mainly used to clarify of milk.

The model is also used to separate similar material in the industry of juice, beverage, Chinese traditional medicine and chemical industry etc.

The machine adopts automatic control, it has the advantages such as high efficiency, low materiel consumption, convenient operation and economic maintenance cost. It adopts small piston structure for gaining variable discharging capacity, and PLC control both partly and fully discharging in order to get rid of sediment.

The clear liquid is pumped out by centripetal pump, the sludge is discharged automatically and partly.

The machine is one kind of rotary machine with high speed. After accurate dynamic balancing, it can run for long time with low vibration, safety and security.

The design, product and acceptance are conformed to the standard of JB/T8103.3 Disc Separator-Part 3: Milk disc separator, GB19814-2005 Separator: Safety requirements, Q/LZ741-2005 Disc separator design standard, GB/T10894-2004 Separator machine:Test methods for noise generator, GB/T10895-2004 Separator centrifuge: Test methods for machine vibration.

Application:

Milk separator machine is mainly used skim milk, whey protein isolate, butter, wheat shock shower, casein, cheese production, anhydrous butter centrifuge enrichment and other production processes for medium to large dairy industry enterprises. Equipment uses a closed structure, with milk contact parts made of stainless steel, in line with national food hygiene standards. Device according to user requirements, can also be used in the milk, milk residue, after condensation casein, the protein and whey protein isolate, and whey clarification and purification.

Drum introduction

The drum body is made of 2507 duplex stainless steel and is suitable for CIP cleaning. Other contacted parts made of superior stainless steel which meets the food degree requirements Drum has such features by the precise dynamic balance check as small vibration to the machine, long continuous-running time and safe and reliable performance.

Main technical parameters

Discharging type

Variable capacity discharge

Fresh milk capacity

L/h

15000~20000

Impurity in milk after separation

Mg/kg

1

Outlet pressure of clear liquid

Mpa

≤ 0.2

Motor power

Kw

22

Net weight

kg

1580

Gross weight

kg

1800

Overall dimension (L × W × H)

mm

1479 × 1289 × 1583

Packing size (L × W × H)

mm

1900 × 1570 × 2050

Drum rotational speed

r/min

5790

G force

Fr

>10000

Drum diameter

mm

510

Start mode

Variable frequency starting

Installation notice

1. For maintenance and repair, please leave enough space around the separator when install it.

2. The installation base should be firm and level.

3. All the pipes connecting with the separator should be flexible pipe.

4. The operation water of the separator must be soft water, the pressure of which is between 0.025 and 0.03Mpa.

More pictures

High Speed Food Centrifuge , Milk Separator With Large Capacity For Beverage Juice ClarificationHigh Speed Food Centrifuge , Milk Separator With Large Capacity For Beverage Juice Clarification

Guarantee

Peony Centrifuge has been dedicated to producing machinery and equipments and carrying out facility construction, pursuing the best quality and producing the best product at the same time. We are committed to reward you with a better quality in return for our interest in and faith toward. We will do our utmost for one more stepping forward, based on our infinite services and trust to customers.
