Simple Automatic Skid Mounted Disc Bowl Centrifuge For Marine Fuel Oil Purifying
Description:
Model PDSD14000 Skid is automatic continuous equipment for MDO (marine diesel oil) purifying. It is mainly to remove water and mechanical impurities from diesel oil, lubricating oil, and other mineral oil in marine diesel engine units and land-used diesel generator units of power stations so as to reduce wear of the diesel engine and other machines and prolong engine life. It is also used to separate two unsolvable liquids with different specific gravity or remove a small number of solid particles from the liquid.
Main Technical Specification:
| Model | PDSD14000 |
| Rated Capacity | 14000L/H(0# diesel oil) |
| Bowl rotating speed | 7800 rpm |
| The output pressure of clear oil | ≤ 0.2 Mpa |
| The output pressure of sewage | ≤ 0.3MPa |
| Motor | 11-15KW |
| Discharge type | Variable discharge |
| Output type | Centripetal pump |
| Overall size of single machine (LXWXH) | 1200x810x1225(mm x mm x mm) |
Advantages:
1. Moisture sensor(No-gravity ring) technology is adopted to ensure the quality of the oil after separation.
2. Bowl with a full hydraulic structure brings more thorough stage discharge and more stable and reliable performance.
3. The new type of seamless belt drive(No second tensioning required) brings a more reliable structure and
a more simplified mechanical structure.
4. High rotating speed ensures the best separation effect.
5. Our separator is low power consumption and lightweight, which is in accordance with the
requirements of the national industry.
Peony organizes the model selection question as below:
1) How many kinds of oil can you separate?
This series separator is widely used for kinds of oils, especially for the Marine diesel oil and the
similar oil, such as light fuel oil, heavy fuel oil, lubrication oil, steam turbine oil, detergence oil,
engine oil etc
2) How can you select a suitable capacity?
Different oil has different capacity, our 1500L, 2000L, 3000L, 4000L, 5000L, 6000L, 8000L ,10000L
capacity is for the Marine diesel oil 0# as a sample. It also depends on the viscidity and temperature, and
for all the capacity models, we have an oil characteristic sheet to help our customers to find out what
their oil is, and what capacity their oil belongs to.
3) Is your separator self-cleaning?
We have 3 types of discharge means according to different materials and customer's requirements, we
have the self-cleaning model and a manual cleaning model.
1. Manual discharge model for the oil with very less solid component
2. Full discharge model for the big capacity treatment and a little solid component
3. Partly discharge model for the bigger capacity treatment and more solid component
4). Variable discharge model
No.full discharge type and partially discharge type are both self-cleaning models.
4) Will you help us to select the model?
Yes, you can select the model by yourself, or as long as you provide your material characteristic,
we have a professional engineering team to help you select the suitable machine
5 )Do you only have a single machine or unit?
Both we have.
Guarantee
Peony Centrifuge has been dedicated to producing machinery and types of equipment and carrying
out facility construction, pursuing the best quality and producing the best product at the same time.
We are committed to rewarding you with better quality in return for our interest in and faith in you.
We will do our utmost for one more stepping forward, based on our infinite services and trust in
customers.
