304 Steel Belt Conveyor Industrial Dryer Machine For Herbaceous CBD Hemp Plant

ZHANGJIAGANG CITY PEONY MACHINERY CO.,LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment

304 Steel Belt Conveyor Industrial Dryer Machine For Herbaceous CBD Hemp Plant

  • 1
  • 2

Brand Name : Peony

Model Number : Dry Machine

Certification : ISO

Place of Origin : China

MOQ : 1 SET

Price : pls contact me

Payment Terms : L/C, T/T, Western Union

Supply Ability : 20 sets per month

Delivery Time : 60 days

Packaging Details : Standard wooden case

Structural plate steel : Carbon steel

Transmission shaft : Carbon steel

Insulation shield : Carbon steel

Support leg : Carbon steel

Mesh belt : SUS304

Transferring gear : SUS304

Electricity Distribution Controller : SUS304

Air-blower : Carbon steel, 11 kw

Discharge conveyor : 4000*600*2500mm , Power:0.55kw

Centrifugal Exhaust fan : Carbon steel, 5.5kw

Contact Now

304 Steel Belt Conveyor Industrial Dryer Machine For Herbaceous CBD Hemp Plant

Product Description

This equipment is a belt type multilayer continuous dryer. The main parts are made of high quality carbon steel. The stainless steel mesh belt is made of SUS304, it runs smoothly, easy to maintain and has a long service life. The whole machine running speed and drying temperature can according to production needs set. It’s has a high degree of automation, saving labor and improving production efficiency.
The dryer can be used not only for the drying of hemp, marihuana, cannabis , but also for Chinese herbal medicine ,salvia
miltiorrhiza, and ginseng, garlic, ginger and so on. The dryer’s temperature and humidity can be adjusted according to the actual situation.
Fundamental:
The machine can use electric, gas, LPG, coal,biological particles, diesel and other energy heating. The working principle is that the air heated by the heat source in the hot air stove ,is blown by circulation fans into the inside of the drying cabinet body, so that the moisture of the product is evaporated under the heat. Evaporated under the action, the generated moist air discharged to the outside of the device with the exhaust pipe. The machine can continuously feed and make the material run smoothly. During the material conveying process, the gap is conveyed through the intermittent mesh belt to realize the turnover of the material and reach the homogeneity of the heated wind on all surfaces. It can connect with other equipment to achieve continuous operation.
Applications:
The following materials are dried in the pharmaceutical, food, chemical and other industries:
Suitable for slurry, paste, powder materials;
Heat sensitive materials requiring low temperature drying;
Easy to oxidize, explosive, strong irritant, highly toxic materials;
A material that requires recovery of organic solvents.
Features:
Being adapted the heating way of jacket and inner stirring at the same time, its heat conducting area is large and its heat efficiency is high.
Being installed stirring in the machine, it makes raw material in the cylinder form the state of continuous circle inside the
cylinder, so the uniformity to be heated of raw material is raised greatly.
Being installed stirring apparatus in the machine, pulpiness, pastelike mixture or powder raw materials can be dried easy.
Documentation:
1)We will finish test certificates for raw material like for S.S.304&SS316L
2) Also we will submit test certificates for all bought out items like motor.
3) Two copies of operational manual with English will be given at the time of dispatch of machine.
4) All our machines guaranteed for trouble free performance for a period of 12 months from commissioning.
Safety features:
The machines can’t be started without safe earthing.
Technical Parameter:
Model
DWT-1.2-8
DWT-1.2-10
DWT-1.6-8
DWT-1.6-10
DWT-2-8
DWT-2-10
Number of units
4
5
4
5
4
5
Bandwidth(m)
1.2
1.2
1.6
1.6
2
2
Dry section length (m)
8
10
8
10
8
10
Thick material(mm)
10~80
Operating temperature(°C)
60~150
Steam pressure(Mpa)
0.2~0.8
Steam consumption(kg/h)
120~300
150~375
150~375
170~470
180~500
225~600
Drying time(h)
0.2~1.2
0.25~1.5
0.2~1.2
0.25~1.5
0.2~1.2
0.25~1.5
Dry strength(kg/h)
60~160
80~220
75~220
95~250
100~260
120~300
Total fan power(kw)
8.8
11
12
15
16
20
Total equipment power(kw)
10.1
12.3
13.3
16.3
17.3
21.3

Detailed Images

304 Steel Belt Conveyor Industrial Dryer Machine For Herbaceous CBD Hemp Plant304 Steel Belt Conveyor Industrial Dryer Machine For Herbaceous CBD Hemp Plant

Our Service

1. 12 months guarantee period from machine arriving date.
2. Abundant spare parts in stock are available to provide.
3. Our technicians could be dispatched for overseas service.
4. 7*24 hours technical consultation.
5. Your workers could get trained both in our factory and yours.
6. Routine tracing till the machine work properly will be done timely.
7. We will remind you to do the normal maintenance.
8. Your suggestions or any comments & reflection would be treated in priority.
9. Marketing team will visit you during our visit in your country if you require.

FAQ

1. How can we visit your factory?
If you come from abroad, air to Shanghai airport, then take bullet train, about 1 hour from Shanghai to Nanjing South Station; if you come from our domestic city, air or train directly to Nanjing, we will pick you up both in the airport and railway station.

2. Can we visit your end user or contact them?
Yes, users are in domestic and abroad, we can provide you the name list, you can go there or contact for more info.

3. How do you protect the quality?
Our factory is a state owned enterprise with more than 100 years experience, strict operation policy is performed, advanced processing machines guarantee the precision of all components, workers with operation license, parts get
multiprocessing,transmission & electrical parts are of international famous brand. Series of test and inspection are done in the whole producing stage.

4. Will you dispatch technicians for installation and commissioning?
Yes, we can, we do lots of service, please refer to our after sales part.

5. What is your advantages compared with your competitors?
Quality and experience. We are the top centrifuge supplier in China, our designs and structures are similar to world famous
brands.

6. Is your price competitive?
Our price is not the lowest in China as for high quality, but we promise, for the same quality and collocation, our price is the most favourite, for the same price, our quality is definately superior to other brand.

7. Do you have OEM serive? Do you supply the parts?
Yes, we do, as long as you provide us your drawing and detailed requirements.

8. Do you supply second hand centrifuge?
No, we only provide brand new machine.

9. Do you have agent or service center in my country?
We have some partnership in several countries as Indonesia, Brazil, USA, etc. Your are warmly welcomed to work as our agent. At this moment, we have no service center abroad, but we can provide overseas spot and online technical service in time.

10. How can we easily find out the most fit centrifuges?
We have experienced engineer team to help you make the model selection, as long as you provide us the detailed processing material characteristics.


11. What payment mode you accept?

TT, Wester Union and LC at sight.
Our Certification
304 Steel Belt Conveyor Industrial Dryer Machine For Herbaceous CBD Hemp Plant
